Review on methanol as fuel for engines and its future prospect

doi:10.3969/j.issn.1674-8484.2023.05.001

Abstract

Abstract:

Methanol is liquid under ambient temperature and atmosphere, of which is close to gasoline and diesel fuel. It can be produced out by a wide-ranging raw material, such as coal, natural gas, biomass and by carbon dioxide synthetized with hydrogen called the green methanol. The green methanol has been recognized as the fuel with low carbon emission even carbon neutrality, which has been used as marine fuel more and more widely. China is the country with largest productive capacity and production for methanol in global, of which it occupies 60% of global productive capacity and production. China took methanol as fuel to substitute for petroleum oil for many years since 40 years ago. Methanol now has been used as fuel for versatile utility, such as cooking, heat generation for civil and industrial use, furthermore for transportation and constructive machine. The review introduces the methanol production, cognition for methanol toxicity, development of green methanol and practices of methanol in industrial and civil, emphasizes the technical characteristics for utilities in vehicle, marine, locomotive and generation set, and points out the challenges methanol facing with while development as well as its prospect of future development in those fields.

Key words: methanol, methanol fuel, thermal combustion of methanol, methanol vehicles, marine methanol

CLC Number:

TQ517.4

YAO Chunde, YAO Anren. Review on methanol as fuel for engines and its future prospect[J]. Journal of Automotive Safety and Energy, 2023, 14(5): 521-535.

Figures/Tables 21

References 49

[1]	姚春德. 柴油/甲醇二元燃料燃烧理论与实践[M]. 天津: 天津大学出版社, 2015:1-28.
	YAO Chunde. Theory and Practice of Diesel/Methanol Dual Fuel Combustion[M]. Tianjin: Tianjin University Press, 2015: 1-28. (in Chinese)
[2]	中国石化醇醚专业委员会. 2023年中国甲醇燃料调研报告[R]. 中国石油和化工联合会醇醚燃料及醇醚清洁汽车专业委员会, 2013.
	Sinopec Alcohol and Ether Committee. China methanol fuel research report in 2023[R]. Alcohol Ether Fuel and Alcohol Ether Clean Vehicle Professional Committee of China Petroleum and Chemical Industry Federation, 2013. (in Chinese)
[3]	中国汽车报. 专家讲堂: 甲醇毒性问题不应成为甲醇汽车推广障碍[N/OL]. (2018-07-24),https://www.163.com/dy/article/DNGHCBSV0527AUGP.html.
	China Automotive News. Expert Lecture: Methanol toxicity should not become an obstacle to the promotion of methanol vehicles[N/OL]. (2018-07-24),https://www.163.com/dy/article/DNGHCBSV0527AUGP.html. (in Chinese)
[4]	工信部甲醇汽车试点专家组. 甲醇汽车试点工作总结报告[R]. 2018.
	MIIT methanol vehicle pilot expert group. Methanol vehicle pilot work summary report[R]. 2018.
[5]	小兵咨询看新闻. 山西省, 绿色甲醇燃料靠谱吗?[EB/OL]. (2023-02-18), https://www.sohu.com/a/64266 4096_121123735.
	Soldier consult to see the news. Shanxi Province, green methanol fuel reliable?[EB/OL]. (2023-02-18), https://www.sohu.com/a/64266 4096_121123735. (in Chinese)
[6]	乔治 A. 奥拉, 阿兰 · 戈佩特, G. K. 苏耶 · 普拉卡西, 著. 跨越油气时代:甲醇经济 (第2版)[M]. 夏磊, 胡金波,译. 北京: 化学工业出版社, 2017:242-249.
	Ora A G, Goeppert A, Suye · Prakash K G. Byond Oil and Gas:The Methanol Economy (2 Edit)[M]. XIA Lei, HU Jinbo, Translated. Beijing: Chemical Industry Press, 2017: 242-249. (in Chinese)
[7]	河南日报客户端. 河南安阳:十万吨级绿色低碳甲醇工厂投产[N/OL]. (2023-02-22), https://baijiahao.baidu.com/s?id=1758460185982350841&wfr=spider&for=pc.
	Henan Daily client. Anyang, Henan: 100 000 tons of green low-carbon methanol plant[N/OL]. (2023-02-22), (in Chinese)
[8]	霍鸿宇. 兰州新区千吨级“液态太阳燃料合成示范项目”通过科技成果鉴定[N/OL]. 甘肃日报. (2020-10-18),https://m.gmw.cn/baijia/2020-10/18/1301686122.html.
	HUO Hongyu. The thousand-ton liquid solar fuel synthesis demonstration project in “ Lanzhou New District ” passed the appraisal of scientific and technological achievements[N/OL]. Gansu Daily. (2020-10-18),https://m.gmw.cn/baijia/2020-10/18/1301686122.html. (in Chinese)
[9]	中氢互联, 山东. 450万绿色甲醇产能达成！绿氢又一赛道格局打开！[EB/OL]. (2023-07-04), https://www.163.com/dy/article/I8QKCVKQ05562LDO.html.
	China Hydrogen Interconnection, Shandong. 4.5 million green methanol production capacity reached! Green hydrogen another track pattern open![EB/OL]. (2023-07-04), https://www.163.com/dy/article/I8QKCVKQ05562LDO.html. (in Chinese)
[10]	鹿群. 超级芦竹制负碳绿色甲醇技术[C/OL]// 甲醇经济论坛专业会议,晋中,(2023-09-08), https://www.sohu.com/a/718867342_121106854.
	LU Qun. Technology of super arunax to produce negative carbon green methanol[C/OL]// Meth Econ Foru Prof Conf, Jinzhong. (2023-09-08), https://www.sohu.com/a/718867342_121106854. (in Chinese)
[11]	李峯华. 甲醇燃料燃烧技术在陶瓷烧制领域上的应用[C] // 2021年甲醇热力燃烧线上会议集,工信部甲醇汽车推广应用专家指导委员会, 2021.
	LI Fenghua. The application of methanol fuel combustion technology in the field of ceramic firing[C]// 2021 Conf Meth Therm Combust. The Expert Steering Committee for the Promotion and Application of Methanol Vehicles of MIIT. (in Chinese)
[12]	张松. 70蒸吨甲醇燃料制热锅炉安装工程改造和安全运行简介[C]// 2021年甲醇热力燃烧线上会议集,工信部甲醇汽车推广应用专家指导委员会, 2021.
	ZHANG Song. Introduction to the installation engineering transformation and safe operation of 70 tons methanol fuel heating boiler[C]// 2021 Conf Therm Combust meth(online), MIIT Expert Steering Committee for the Promotion and Application of Methyl Alcohol Vehicles, 2021. (in Chinese)
[13]	李峯华. 甲醇专用燃烧器系统应用于烟叶烤房改造项目报告[C]// 2021年甲醇热力燃烧线上会议集,工信部甲醇汽车推广应用专家指导委员会, 2021.
	LI Fenghua. Report on the application of methanol special burner system in tobacco curing room renovation project[C]// 2021 Meet Meth Therm Combust (online). Expert Steering Committee of Methanol Automobile Promotion and Application of MIIT, 2021. (in Chinese)
[14]	李峯华. 甲醇燃料燃烧技术在农业大棚中的应用[C]// 2021年甲醇热力燃烧线上会议集. 工信部甲醇汽车推广应用专家指导委员会, 2021.
	LI Fenghua. Application of methanol fuel combustion technology in agricultural greenhouses[C]// 2021 Conf Meth Therm Combust. Expert Steering Committee of Methanol Vehicle Promotion and Application of MIIT, 2021. (in Chinese)
[15]	Reed B T, Lerner M R. Methanol: A versatile fuel for immediate use[J]. Science, 1973, 12, 182: 1299-1304.
[16]	Davis C S, Susan E. Williams. Transportation Energy Data Book (35 Edit)[M]. Oak Gidge National Laboratory, ORNL-6992, Edition 35 of ORNL-5198, 2016.
[17]	中国汽车网. 2018年汉诺威商用车展:让我们看到了未来卡车的新趋势[EB/OL]. (2018-09-21), https://www.yoojia.com/article/9257827943732869750.html.
	China Automotive Network. Hannover commercial motor show 2018: Let us see the new trend of the future of trucks[EB/OL]. (2018-09-21), https://www.yoojia.com/article/9257827943732869750.html. (in Chinese)
[18]	郑州外资企业服务中心. 工信部节 [2012]42号: 工业和信息化部关于开展甲醇汽车试点工作的通知[EB/OL]. (2017-02-03), https://www.waizi.org.cn/law/16691.html.
	Zhengzhou Foreign Enterprise Service Center.MIIT [2012] No. 42: Notice of MIIT on the pilot work of methanol vehicles[EB/OL]. (2017-02-03), https://www.waizi.org.cn/law/16691.html. (in Chinese)
[19]	工业和信息化部网站. 八部门关于在部分地区开展甲醇汽车应用的指导意见[EB/OL]. (2019-03-20),
	MIIT website. Eight Departments of guidance on the application of methanol in some areas[EB/OL]. (2019-03-20), http://www.gov.cn/xinwen/2019-03/20/content_5375348.htm. (in Chinese)
[20]	百度. 吉利甲醇汽车的工作原理[EB/OL]. (2023-01-30),https://zhidao.baidu.com/question/1447503620594903260.html.
	Baidu. Geely methanol car working principle[EB/OL]. (2023-01-30), https://zhidao.baidu.com/question/1447503620594903260.html. (in Chinese)
[21]	YAO Chunde, Cheung S C, CHENG Chuanhui, et al. Effect of diesel/methanol compound combustion on diesel engine combustion and emissions[J]. Energ Conv Manag, 2008, 49: 1696-1704. doi: 10.1016/j.enconman.2007.11.007 URL
[22]	姚春德, 李云强, 王银山, 等. 进气预混乙醇对柴油机炭烟和NO_x排放的影响参数研究[J]. 燃烧科学与技术, 2004, 10(6):529-534.
	YAO Chunde, LI Yunqiang, WANG Yinshan, et al. Study on reduction of PM and NO_x by pre-mixed methanol through intake manifold on a diesel engine[J]. Combust Sci Tech, 2004, 10(6):529-534. (in Chinese)
[23]	Reitz D R, Duraisamy G. Review of high efficiency and clean reactivity controlled compression ignition (RCCI) combustion in internal combustion engines[J]. Prog Energ Combust Sci, 2015, 46: 12-17. doi: 10.1016/j.pecs.2014.05.003 URL
[24]	MA Baodong, YAO Anren, YAO Chunde, et al. Multiple combustion modes existing in the engine operating in disel methanol dual fuel[J]. Energy, 2021, 234:No. 121285.
[25]	WEI Lijiang, YAO Chunde, HAN Guopeng, et al. Effects of methanol to diesel ratio and diesel injection timing on combustion, performance and emissions of a methanol port premixed diesel engine[J]. Energy, 2016, 95: 223-232. doi: 10.1016/j.energy.2015.12.020 URL
[26]	WEI Hongyuan, YAO Chunde, DOU Zhancheng, et al. Comparison of the conversion efficiency of DOC and DPOC to unregulated emissions from a DMDF engine[J]. Fuel, 2017, 204: 71-84. doi: 10.1016/j.fuel.2017.05.021 URL
[27]	CHEN Chao, YAO Anren, YAO Chunde, et al, Experimental study of the active and passive regeneration procedures of a diesel particulate filter in a diesel methanol dual fuel engine[J]. Fuel, 2020, 264: No.116801.
[28]	QU Guofan, YAO Anren, CHEN Chao, et al. Effect of EGR strategy on combustion and emission of DMDF engine for meeting China VI emission legislation[J]. Fuel, 2021, 299: No.120879.
[29]	姚安仁, 刘军恒, 魏立江, 等. 柴油/甲醇组合燃烧车辆的道路试验[J]. 中国公路学报, 2012, 25(6): 140-146.
	YAO Anren, LIU Junheng, WEI Lijiang, et al. Field test of HD truck with turbo-intercooled DMCC diesel engine[J]. Chin J Highway Transport, 2012, 25(6): 140-146. (in Chinese)
[30]	齐洪元. 重载压燃式甲醇发动机研发与应用[C/OL]// 甲醇经济论坛专业会议,晋中, (2023-09-08). http://www.sx.Xinhuanet.com/20230908/49f5323a82a8435a8399f2c21388bd88/c.html.
	QI Hongyuan. Development and application of heavy-duty compression combustion methanol engine[C/OL]// Meth Econ Foru Prof Conf, Jinzhong. (2023-09-08), http://www.sx.Xinhuanet.com/20230908/49f5323a82a8435a8399f2c21388bd88/c.html. (in Chinese)
[31]	IMO. Interim guidelines for the safety of ships using methyl/ethyl alcohol as fuel[R]. 2020.
[32]	搜狐网. A. P. 穆勒—马士基将于2023年运营全球第一艘碳中和船舶[EB/OL]. 2021. (2021-02-17), https://www.sohu.com/a/451132350_654163.
	Sohu Web site. A. P. Moller - Maersk will operate the world's first carbon-neutral ship in 2023[EB/OL]. 2021. (2021-02-17), https://www.sohu.com/a/451132350_654163. (in Chinese)
[33]	中国船级社. CCS船舶绿色生态规范标准体系[EB/OL]. (2023-5-19), https://www.sohu.com/a/677123438_120056227.
	China Classification Society. CCS ship green ecological code standard system[EB/OL]. (2023-5-19), https://www.sohu.com/a/677123438_120056227. (in Chinese)
[34]	姚安仁, 贾宝富, 马宝东, 等. 甲醇燃料在船舶内燃机动力中的应用[J]. 柴油机, 2022(5): 2-8.
	YAO Anren, JIA Baofu, MA Baodong, et al. Study on applicaition of methanol fuel to marine power[J]. Diesel, 2022(5): 2-8. (in Chinese)
[35]	古金培. 东莞传动电喷科技有限公司[C]// 船舶动力应用甲醇燃料技术交流会. 中国内燃机工业协会,北京, 2017.
	GU Jinpei. Dongguan transmission electric spray technology Co., LTD[C]// Mari Power Appl Meth Fuel Tech Exch Meet. China Internal Combustion Engine Industry Association, Beijing, 2017. (in Chinese)
[36]	YAO Chunde, PAN Wang, YAO Anren. Methanol fumigation in compression-ignition engines: A critical review of recent academic and technological developments[J]. Fuel, 2017, 209: 713-732. doi: 10.1016/j.fuel.2017.08.038 URL
[37]	Andersson K, Salazar M C, Methanol as a marine fuel report[R]. Methanol Institute, 2015.
[38]	新能源网. 世界上第一艘以甲醇为动力的商用船诞生五周年[EB/OL]. (2020-04-16), http://www.china-nengyuan.com/news/154765.html.
	New Energy network. The 5th anniversary of the birth of the world's first commercial ship powered by methanol[EB/OL]. ( 2020-04-16), http://www.china-nengyuan.com/news/154765.html. (in Chinese)
[39]	MAN. World-first order for methanol engine within container segment[EB/OL]. 2021. (2021-07-27), https://www.man-es.com/company/press-releases/press-details/2021/07/27/world-first-order-for-methanol-engine-within-container-segment.
[40]	Adfhbxs. The Methanol-fuelled MAN B&W LGIM Engine[EB/OL]. (2021-08-16), http://www.360doc.com/content/21/0816/21/61907111_991338103.shtml.
[41]	WANG Hui, YAO Anren, YAO Chunde, et al. Investigation to meet China II emission legislation for marine diesel with diesel methanol compound combustion technology[J]. J Envi Sci, 2020, 96: 99-108.
[42]	姚春德, 王辉, 姚安仁, 等. DMCC技术在高速船用柴油机上的应用研究[J]. 哈尔滨工程大学学报, 2021, 42(1): 112-118.
	YAO Chunde, WANG, YAO Anren, et al. Performance study of DMCC technology under high-speed marine engine[J]. J Harbin Engi Univ, 2021, 42(1): 112-118. (in Chinese)
[43]	刘明宽, 姚安仁, 吴亦宁, 等. 柴油甲醇组合燃烧对机车柴油机排放性能的研究[J]. 柴油机, 2020, 42(293): 1-6.
	LIU Mingkuan, YAO Anren, WU Yining, et al. The impacts of diesel/methanol compound combustion on nox and other emissions of locomotive-diesel engines[J]. Diesel, 2020, 42(293): 1-6. (in Chinese)
[44]	艾有楷, 姚安仁, 鲍祥福, 等. 柴油甲醇组合燃烧技术在发电机组产品开发中的应用[J]. 柴油机, 2022(9): 1-8.
	AI Youkai, YAO Anren, BAO XiangFu, et al. Application of diesel methanol compound combustion technology in product development of generator sets[J]. Diesel, 2022(9): 1-8. (in Chinese)
[45]	许书军, 许广健. 中国甲醇汽车产业现状及发展策略研究[J]. 交通节能与环保, 2022, 18(4): 5-49.
	XU Shunjun, XU Guangjian, Research on current situation and development strategy of methanol automobile industry in china[J]. Transport Energ Conse Envi Protect, 2022, 18(4): 5-49. (in Chinese)
[46]	商车帮. 以吉利甲醇汽车为例,浅谈甲醇商用车在我国的发展趋势[EB/OL]. (2022-08-11). https://baijiahao.baidu.com/s?id=1740828274158420131&wfr=spider&for=pc. (in Chinese)
	The dealer Car Gang. Taking Geely methanol automobile as an example, discussion on the development trend of methanol commercial vehicles in China[EB/OL]. (2022-08-11). https://baijiahao.baidu.com/s?id=1740828274158420131&wfr=spider&for=pc. (in Chinese)
[47]	刘明月. 全国机动车保有量达4.26亿辆机动车发展趋势如何?[EB/OL]. (2023-08-03), https://www.chinairn.com/news/20230803/11360912.shtml.
	LIU Mingyue. What is the development trend of 426 million motor vehicles in China? [EB/OL]. (2023-08-03), https://www.chinairn.com/news/20230803/11360912.shtml. (in Chinese)
[48]	韩国鹏, 姚安仁, 姚春德, 等. 甲醇对直流泵的腐蚀机理及改进措施腐蚀和防护[J]. 2015, 36(9): 878-882.
	HAN Guopeng, YAO Anren, YAO Chunde, et al. The corrosion mechanism of the methanol to DC pump and some improvement measures[J]. Corros Protect, 2015, 36(9): 878-882. (in Chinese)
[49]	姚春德, 赵新峰, 沈恩华, 等. 甲醇汽油对汽车橡胶元件溶胀的力学分析[J]. 汽车工程, 2012(10): 909-913
	YAO Chunde, ZHAO Xinfeng, SHEN Enhua, et al. The mechanical analysis of the swelling of the rubber components on the vehicle for methanol gasoline[J]. Autom Engineering, 2012(10): 909-91. (in Chinese)

性质/单位	甲醇	汽油	柴油
化学式	CH₃OH	C4~C14的烃类化合物	C16~C23的烃类化合物
相对分子质量	32.04	95~120	180~200
C/H原子量比	3.0	5.6~7.4	6.4~7.2
密度（20oC） /（kg·L^-1）	0.792	0.72~0.78	0.82~0.86
冰点/ oC	-96	-57	-1~-4
沸点/ oC	64.7	27~225	180~370
闪点/ oC	12	45	75
自燃温度/ oC	450	350~468	260~350
汽化潜热/（kJ·kg^-1）	1 167	310	270
着火界限（体积分数） / %	6.7~36.5	1.4~6.7	1.5~8.2
低热值/（kJ·kg^-1）	19 930	43 030	42 500
辛烷值（RON）	114.4	89~98	—
十六烷值	3	0~10	45~55
理论空燃比（空气与燃料质量比） /（kg·kg^-1）	6.5	14.8	14.6

性质/单位	甲醇	汽油	柴油
化学式	CH₃OH	C4~C14的烃类化合物	C16~C23的烃类化合物
相对分子质量	32.04	95~120	180~200
C/H原子量比	3.0	5.6~7.4	6.4~7.2
密度（20oC） /（kg·L^-1）	0.792	0.72~0.78	0.82~0.86
冰点/ oC	-96	-57	-1~-4
沸点/ oC	64.7	27~225	180~370
闪点/ oC	12	45	75
自燃温度/ oC	450	350~468	260~350
汽化潜热/（kJ·kg^-1）	1 167	310	270
着火界限（体积分数） / %	6.7~36.5	1.4~6.7	1.5~8.2
低热值/（kJ·kg^-1）	19 930	43 030	42 500
辛烷值（RON）	114.4	89~98	—
十六烷值	3	0~10	45~55
理论空燃比（空气与燃料质量比） /（kg·kg^-1）	6.5	14.8	14.6

指标		甲醇	汽油
吸入低浓度	毒性	3	10
吸入低浓度	可能性	—	10
吸入高浓度	毒性	10	10
吸入高浓度	可能性	3	4
皮肤接触	毒性	9	8
皮肤接触	可能性	3	3
口服	毒性	10	10
口服	可能性	8（2）	3

指标		甲醇	汽油
吸入低浓度	毒性	3	10
吸入低浓度	可能性	—	10
吸入高浓度	毒性	10	10
吸入高浓度	可能性	3	4
皮肤接触	毒性	9	8
皮肤接触	可能性	3	3
口服	毒性	10	10
口服	可能性	8（2）	3

	排放浓度/ [g·(kWh)^-1]					BTE %
	NO_x	PM	CO	THC	BSFC	BTE %
国VI限值	0.40	10.00	1.50	0.13	—	—
原机	11.35	6.20	0.48	0.21	—	—
原机 + DOC + CDPF	10.64	0.40	0.05	0.14	222.5	38.1
DMCC	0.38	35.02	10.60	3.50	—	—
DMCC + DOC + CDPF	0.36	7.66	0.04	0.35	214.6	39.5
