氨氢融合零碳内燃机燃烧过程综述

doi:10.3969/j.issn.1674-8484.2024.04.001

汽车安全与节能学报 ›› 2024, Vol. 15 ›› Issue (4): 443-466.DOI: 10.3969/j.issn.1674-8484.2024.04.001

• 综述与展望 • 下一篇

氨氢融合零碳内燃机燃烧过程综述

王志¹^,²(), 齐运亮¹^,², 陈清楚¹^,², 李骏¹^,²^,^*()

1.清华大学车辆与运载学院，北京 100084，中国
2.清华大学智能绿色车辆与交通全国重点实验室，北京 100084，中国

收稿日期:2024-07-01 修回日期:2024-08-16 出版日期:2024-08-31 发布日期:2024-09-04
通讯作者: *李骏，教授。E-mail：lijun1958@tsinghua.edu.cn。
作者简介:王志（1972—），男（汉），湖北，教授。E-mail：wangzhi@tsinghua.edu.cn。
王志教授清华大学教授，博士生导师,国家级一流本科课程负责人，清华大学车辆与运载学院副院长，中国汽车工程学会会士，中国汽车工程学会（China-SAE）汽车发动机分会主任委员，中国机械工业教育协会车辆工程专业委员会副主任委员，中国内燃机学会（CSICE）燃料与润滑油分会秘书长。入选国家高层次人才支持计划。长期从事内燃机高效清洁燃烧技术和燃料燃烧化学研究，攻克爆震燃烧机理与控制技术。获中国内燃机学会自然科学一等奖和中国汽车工业技术发明一等奖。主编《汽车动力系统原理》教材。研究领域为爆震燃烧，化学反应动力学、交通能源与智能动力。
李骏教授中国工程院院士，清华大学车辆学院教授、博士生导师，清华大学－一汽解放汽车有限公司智能碳中和车辆科技联合研究中心主任。现任中国汽车工程学会（China-SAE）荣誉理事长、国家智能网联汽车创新中心主任、中国汽车科技进步奖评委会主任、中国智能网联汽车产业创新联盟理事长，Automotive Innovation学术期刊主编。曾任中国第一汽车集团有限公司总工程师、技术中心主任、2012—2014年国际汽车工程师学会联合会（International Federation of Automotive Engineering Societies, FISITA）主席、中国汽车工程学会理事长。研究领域为智能网联汽车预期性功能安全、氨氢融合燃料发动机、氢燃料发动机。
基金资助:
国家自然科学基金资助项目(T2241003);国家自然科学基金资助项目(T2341002)

Overview of the combustion of ammonia-hydrogen internal combustion engines

WANG Zhi¹^,²(), QI Yunliang¹^,², CHEN Qingchu¹^,², LI Jun¹^,²^,^*()

1. School of Vehicle and Mobility, Tsinghua University, Beijing 100084, China
2. State Key Laboratory of Intelligent Green Vehicle and Mobility, Tsinghua University, Beijing 100084, China

Received:2024-07-01 Revised:2024-08-16 Online:2024-08-31 Published:2024-09-04
About author:Prof. WANG Zhi, He is a professor at Tsinghua University, a Ph D supervisor, the director of the National First-Class Undergraduate Course, a deputy dean of the School of Vehicle and Mobility at Tsinghua University, a fellow of China Society of Automotive Engineers (China-SAE), the chairman of the Automotive Engine Committee of China-SAE, a deputy director of the Vehicle Engineering Professional Committee of the China Association of Mechanical Education, and the secretary-general of the Fuel and Lubricants Committee of the Chinese Society for Internal Combustion Engines (CSICE). He has been selected for the National High-Level Talent Support Program. He has long been engaged in the research of high-efficiency and clean combustion technology for internal combustion engines and fuel combustion chemistry, and has made breakthroughs in the mechanism and control technology of knocking combustion. He has received the First Prize of the Natural Science Award from CSICE and the First Prize of the Technical Invention Award from China-SAE. He is the chief editor of the textbook Principles of Automotive Power Systems. His research areas include knocking combustion, chemical reaction kinetics, transportation energy, and intelligent power systems.
Prof. LI Jun, He is an academician of the Chinese Academy of Engineering, a professor, and a PhD supervisor in School of Vehicle and Mobility, Tsinghua University，the director of Tsinghua University-Faw Jiefang Automotive Co., Ltd. Joint Research Center for Intelligent Carbon Neutral Vehicle Technology. He also serves as the Honorary Chairman of the China Society of Automotive Engineers (China-SAE), the director of the National Innovation Center of Intelligent and Connected Vehicles, the chairman of the China Automotive Industry Progress Award, and the chairman of the China Industry Innovation Alliance for the Intelligent and Connected Vehicles. Additionally, he is the editor-in-chief of the academic journal Automotive Innovation. Previously, he was the chief engineer of FAW group，and the director of FAW Research and Development Center，the president of the International Federation of Automotive Engineering Societies (FISITA) from 2012 to 2014, and the chairman of China-SAE. His research interests include safety of the intended functionality for intelligent connected vehicles, ammonia-hydrogen hybrid fuel engines, and hydrogen fuel engines.

摘要/Abstract

摘要：

随着中国“碳达峰”与“碳中和”目标的提出，内燃机低碳化、零碳化势在必行。氨作为零碳燃料和氢的高能量密度载体，是实现碳中和有潜力的替代燃料。研发氨氢燃烧技术，实现氨高效清洁融合燃料零碳大功率内燃机高效近零排放对全球气候治理具有重大意义。该文在分析氨作为未来绿色能源的潜力及其在内燃机中实际应用的基础上，从氨氢内燃机的燃烧模式、氨氢燃料的燃烧化学反应动力学、氨氢燃料供给方式等方面综述了氨氢内燃机的燃烧的最新进展，对比分析了火花点燃/均质压燃/射流引燃3种燃烧模式、氨气道喷射/液氨缸内直喷2种燃料供给方式、主动射流/被动射流2种点火方式，提出并论述了基于氨在线裂解制氢实现基于单一液氨燃料油箱的氨氢融合燃烧，是内燃机实现碳中和的极具潜力的技术路线，指出了氨氢内燃机喷雾、燃烧和氮基排放控制三方面需要解决的关键技术和科学问题。研究表明：氨氢融合内燃机采用微量氢气（小于3%）引燃氨混合气，可以获得稳定燃烧和高热效率，并拓展稀然极限。氨氢融合零碳大功率内燃机作为氨燃料高效可靠的应用载体，在重型车辆、工程机械、远洋船舶、发电等多个领域具备广泛的应用潜力与价值，氨氢内燃机的研发可推动基础燃烧理论的进步，也可以促进中国内燃机产业迈上新的台阶。

关键词: 氨氢融合, 零碳内燃机, 燃烧模式, 燃烧化学反应动力学

Abstract:

With the introduction of Chinese goals of “carbon peak” and “carbon neutrality”, the low-carbon and zero-carbon transition of internal combustion engines is imperative. Ammonia, as a zero-carbon fuel and a high-energy-density carrier for hydrogen, is a promising alternative fuel for achieving carbon neutrality in the near to mid-term. Developing ammonia-hydrogen combustion technology for high-power, zero-carbon internal combustion engines is of significant importance for global climate governance. This paper analyzes the potential of ammonia as a future green energy source and its practical applications in internal combustion engines. It reviews the latest advancements in ammonia-hydrogen engine combustion from the aspects of combustion modes, reaction kinetics of ammonia-hydrogen fuel, and fuel supply methods, comparing three combustion modes (spark ignition/homogeneous compression ignition/jet ignition), two ammonia supply methods (gaseous port injection/liquid ammonia direct injection), and two jet ignition methods (active/passive). A promising technology of ammonia-hydrogen synergy combustion based on online ammonia cracking to produce hydrogen from a single liquid ammonia fuel tank is proposed and discussed. Key technical and scientific issues to be addressed in spray, combustion, and nitrogen-based emission control are also pointed out. Research indicates that using a small amount of hydrogen (less than 3%) to ignite ammonia-air mixtures in ammonia-hydrogen engines can achieve stable combustion and high thermal efficiency while extending the lean limit. Ammonia-hydrogen synergy zero-carbon high-power internal combustion engines, as efficient and reliable application carriers for ammonia fuel, have broad application potential and value in heavy-duty vehicles, construction machinery, ocean-going vessels, and power generation. The development of ammonia-hydrogen engines can advance fundamental combustion theory and revitalize China's internal combustion engine industry.

Key words: ammonia-hydrogen synergy, zero-carbon engine, combustion mode, reaction kinetics

中图分类号:

TK467.1+4

王志, 齐运亮, 陈清楚, 李骏. 氨氢融合零碳内燃机燃烧过程综述[J]. 汽车安全与节能学报, 2024, 15(4): 443-466.

WANG Zhi, QI Yunliang, CHEN Qingchu, LI Jun. Overview of the combustion of ammonia-hydrogen internal combustion engines[J]. Journal of Automotive Safety and Energy, 2024, 15(4): 443-466.

图/表 27

参考文献 120

[1]	Mørch C S, Bjerre A, Gøttrup M P, et al. Ammonia / hydrogen mixtures in an SI-engine: Engine performance and analysis of a proposed fuel system[J]. Fuel, 2011, 90(2): 854-864.
[2]	Frigo S, Gentili R. Analysis of the behaviour of a 4-stroke Si engine fuelled with ammonia and hydrogen[J]. Int'l J Hydro Energ, 2013, 38(3): 1607-1615.
[3]	Comotti M, Frigo S. Hydrogen generation system for ammonia-hydrogen fuelled internal combustion engines[J]. Int'l J Hydro Energ, 2015, 40(33): 10673-10686.
[4]	Pochet M, Truedsson I, Foucher F, et al. Ammonia-hydrogen blends in homogeneous-charge compression-ignition engine[R]. SAE Technical Paper, 2017-24-0087.
[5]	Lhuillier C, Brequigny P, Contino F, et al. Experimental study on ammonia/hydrogen/air combustion in spark ignition engine conditions[J]. Fuel, 2020, 269: 117448.
[6]	Pochet M, Jeanmart H, Contino F. A 22: 1 compression ratio ammonia-hydrogen HCCI engine: Combustion, load, and emission performances[J]. Front Mech Engineering, 2020, 6: 43.
[7]	Mounaïm-Rousselle C, Bréquigny P, Dumand C, et al. Operating limits for ammonia fuel spark-ignition engine[J]. Energies, 2021, 14(14): 4141.
[8]	JI Changwei, GU Xin, WANG Shuofeng, et al. Effect of ammonia addition on combustion and emissions performance of a hydrogen engine at part load and stoichiometric conditions[J]. Int'l J Hydro Energ, 2021, 46(80): 40143-40153.
[9]	GU Xin, JI Changwei, WANG Shuofeng, et al. Effect of ammonia addition on combustion and emission characteristics of hydrogen-fueled engine under lean-burn condition[J]. Int'l J Hydro Energ, 2022, 47(16): 9762-9774.
[10]	GU Xin, JI Changwei, WANG Shuofeng, et al. Effect of different volume fractions of ammonia on the combustion and emission characteristics of the hydrogen-fueled engine[J]. Int'l J Hydro Energ, 2022, 47(36): 16297-16308.
[11]	LIU Zongkuan, ZHOU Lei, ZHONG Lijia, et al. Enhanced combustion of ammonia engine based on novel air-assisted pre-chamber turbulent jet ignition[J]. Energ Con Manag, 2023, 276: 116526.
[12]	LIU Zongkuan, ZHOU Lei, WEI Haiqiao, et al. Experimental investigation on the performance of pure ammonia engine based on reactivity controlled turbulent jet ignition[J]. Fuel, 2023, 335: 127116.
[13]	LIU Zongkuan, ZHOU Lei, ZHONG Lijia, et al. Experimental investigation on the combustion characteristics of NH₃ / H₂ / air by the spark ignition and turbulent jet ignition[J]. Combust Sci Tech, 2024, 196(1): 73-94.
[14]	QI Yunliang, LIU Wei, LIU Shang, et al. A review on ammonia-hydrogen fueled internal combustion engines[J]. eTransportation, 2023, 18: 100288.
[15]	LIN Zhelong, LIU Shang, LIU Wei, et al. Numerical investigation of ammonia-rich combustion produces hydrogen to accelerate ammonia combustion in a direct injection SI engine[J]. Int'l J Hydro Energ, 2024, 49: 338-351.
[16]	WANG Zhi, QI Yunliang, SUN Qiyang, et al. Ammonia combustion using hydrogen jet ignition (AHJI) in internal combustion engines[J]. Energy, 2024, 291: 130407.
[17]	Lhuillier C, Brequigny P, Contino F, et al. Combustion characteristics of ammonia in a modern spark-ignition engine[R]. SAE Technical Paper, 2019-24-0237.
[18]	Lhuillier C, Brequigny P, Contino F, et al. Performance and emissions of an ammonia-fueled SI engine with hydrogen enrichment[R]. SAE Technical Paper, 2019-24-0137.
[19]	Dinesh M H, Pandey J K and Kumar G N. Study of performance, combustion, and NO_x emission behavior of an SI engine fuelled with ammonia/hydrogen blends at various compression ratio[J]. Int'l J Hydro Energ. 2022, 47(60): 25391-25403.
[20]	Dinesh M H, Kumar G N. Effects of compression and mixing ratio on NH₃ / H₂ fueled Si engine performance, combustion stability, and emission[J]. Energ Conv Manag, 2022, 15: 100269.
[21]	LI Jinguang, ZHANG Ren, PAN Jiaying, et al. Ammonia and hydrogen blending effects on combustion stabilities in optical SI engines[J]. Energ Conv Manag, 2023, 280: 116827.
[22]	Frigo S, Gentili R, Doveri N. Ammonia plus hydrogen as fuel in a SI engine: experimental results[R]. SAE Technical Paper, 2012-32-0019.
[23]	Frigo S, Gentili R, De Angelis F. Further insight into the possibility to fuel a SI engine with ammonia plus hydrogen[R]. SAE Technical Paper, 2014-32-0082.
[24]	ZHU Tiankui, YAN Xin, GAO Zhan, et al. Combustion and emission characteristics of ammonia-hydrogen fueled SI engine with high compression ratio[J]. Int'l J Hydro Energ, 2024, 62: 579-590.
[25]	Swift E, Kane S, Northrop W F. Operating range and emissions from ammonia-hydrogen mixtures in spark-ignited engines[C]// Inter Combust Engi Divi Fall Tech Conf. American Society of Mechanical Engineers, 2022, 86540: V001T02A013
[26]	ZHANG Ridong, ZHANG Qihang, QI Yunliang, et al. Investigation on flame propagation and end-gas auto-ignition of ammonia/hydrogen in a full-field-visualized rapid compression machine[J]. Proc Combust Inst, 2024, 40(1): 105455.
[27]	Gray J T, Dimitroff E, Meckel N T, et al. Ammonia fuel: Engine compatibility and combustion[J]. SAE Trans, 1967, 75: 785-807.
[28]	Van Blarigan P. Advanced internal combustion electrical generator[R]. 2001, NREL/CP-610-32405.
[29]	Dimitriou P, Javaid R. A review of ammonia as a compression ignition engine fuel[J]. Int'l J Hydro Energ, 2020, 45(11): 7098-7118.
[30]	Mounaïm-Rousselle C, Mercier A, Brequigny P, et al. Performance of ammonia fuel in a spark assisted compression ignition engine[J]. Int'l J Engi Res. 2021, 23(5): 781-792.
[31]	Reggeti S, Kane S, Northrop W. Experimental investigation of spark-assisted compression-ignition with ammonia-hydrogen blends[J]. J Ammonia Energy, 2023, 1(1): 91-105.
[32]	刘尚, 蔡开源, 刘伟, 等. 多燃烧模式下掺氨发动机试验研究[J]. 汽车安全与节能学报. 2022, 13(1): 142-148.
	LIU Shang, CAI Kaiyuan, LIU Wei, et al. Experimental study on different combustion modes of ammonia blended engines[J]. J Autom Safe Energ, 2022, 13(1): 142-148.
[33]	Benekos S, Frouzakis C E, Giannakopoulos G K, et al. A 2-D DNS study of the effects of nozzle geometry, ignition kernel placement and initial turbulence on prechamber ignition[J]. Combust Flame, 2021, 225: 272-290.
[34]	ZHOU Lei, ZHONG Lijia, LIU Zongkuan, et al. Toward highly-efficient combustion of ammonia-hydrogen engine: Prechamber turbulent jet ignition[J]. Fuel, 2023, 352: 129009.
[35]	LIU Zongkuan, ZHOU Lei, ZHONG Lijia, et al. Reactivity controlled turbulent jet ignition (RCTJI) for ammonia engine[J]. Int'l J Hydro Energ, 2023, 48(33): 12519-12522.
[36]	LI Zhuohang, ZHANG Zhenyingnan, FAN Yezeng, et al. Fuel reactivity stratification assisted jet ignition for low-speed two-stroke ammonia marine engine[J]. Int'l J Hydro Energ, 2024, 49: 570-585.
[37]	ZHAO Ziqing, WANG Zhi, QI Yunliang, et al. Experimental study of combustion strategy for jet ignition on a natural gas engine[J]. Int'l J Engi Res, 2022, 23(1): 104-119.
[38]	ZHANG Tianyue, JI Changwei, WANG Zhe, et al. Experimental investigation on the combustion characteristics of ultra-lean premixed hydrogen/air using turbulent jet ignition[J]. Energy, 2024, 293: 130573.
[39]	Korb B, Kuppa K, Nguyen H D, et al. Experimental and numerical investigations of charge motion and combustion in lean-burn natural gas engines[J]. Combust Flame, 2020, 212: 309-322.
[40]	Ambalakatte A, Cairns A, Geng S, et al. Experimental comparison of spark and jet ignition engine operation with ammonia/hydrogen co-fuelling[R]. SAE Technical Paper, 2024-01-2099.
[41]	Pearsall T J, Garabedian C G. Combustion of anhydrous ammonia in diesel engines[R]. SAE Technical Paper, 1967, 670947.
[42]	Dodd R, Mullett J, Carroll S, et al. Laser ignition of an IC test engine using an Nd: YAG laser and the effect of key laser parameters on engine combustion performance[J]. Lasen Engi, 2007, 17(3): 1554-2971.
[43]	Kopecek H, Wintner E, Lackner M, et al. Laser-stimulated ignition in a homogeneous charge compression ignition engine[R]. SAE Technical Paper, 2004-01-0937.
[44]	Faingold G, Kalitzky O, Lefkowitz J K. Plasma reforming for enhanced ammonia-air ignition: A numerical study[J]. Fuel Commun. 2022, 12: 100070.
[45]	Shahsavari M, Konnov A A, Valera-Medina A, et al. On nanosecond plasma-assisted ammonia combustion: Effects of pulse and mixture properties[J]. Combust Flame. 2022, 245: 112368.
[46]	Taneja T S, Johnson P N, Yang S. Nanosecond pulsed plasma assisted combustion of ammonia-air mixtures: Effects on ignition delays and NO_x emission[J]. Combust Flame, 2022, 245: 112327.
[47]	ZHAO Ziqing, QI Yungliang, CAI Kaiyuan. Research on the combustion mechanism of plasma-induced ammonia-hydrogen jet ignition engine[J]. Int'l J Hydro Energ, 2024, 65: 398-409.
[48]	Miller J A, Bowman C T. Mechanism and modeling of nitrogen chemistry in combustion[J]. Prog Energ Combust Sci, 1989, 15(4): 287-338.
[49]	Miller J A, Smooke M D, Green R M, et al. Kinetic modeling of the oxidation of ammonia in flames[J]. Combust Sci Tech, 1983, 34(1-6): 149-176.
[50]	Dean A M, Chou M S, Stern D. Kinetics of rich ammonia flames[J]. Int'l J Chem Kinet, 1984, 16(6): 633-653.
[51]	Salimian S, Hanson R K, Kruger C H. High temperature study of the reactions of O and OH with NH₃[J]. Int'l J Chem Kinet, 1984, 16(6): 725-739.
[52]	Lindstedt R P, Lockwood F C, Selim M A. Detailed kinetic modelling of chemistry and temperature effects on ammonia oxidation[J]. Combust Sci Tech, 1994, 99(4-6): 253-276.
[53]	Skreiberg Ø, Kilpinen P, Glarborg P. Ammonia chemistry below 1 400 K under fuel-rich conditions in a flow reactor[J]. Combust Flame, 2004, 136(4): 501-518.
[54]	Konnov A A. Implementation of the NCN pathway of prompt-NO formation in the detailed reaction mechanism[J]. Combust Flame, 2009, 156(11): 2093-2105.
[55]	TIAN Zhenyu, LI Yuyang, ZHANG Lidong, et al. An experimental and kinetic modeling study of premixed NH₃ / CH₄ / O₂ / Ar flames at low pressure[J]. Combust Flame, 2009, 156(7): 1413-1426.
[56]	Duynslaegher C, Jeanmart H, Vandooren J. Kinetics in ammonia-containing premixed flames and a preliminary investigation of their use as fuel in spark ignition engines[J]. Combust Sci Tech, 2009, 181(8): 1092-1106.
[57]	Mendiara T, Glarborg P. Ammonia chemistry in oxy-fuel combustion of methane[J]. Combust Flame, 2009, 156(10): 1937-1949.
[58]	Glarborg P, Miller J A, Ruscic B, et al. Modeling nitrogen chemistry in combustion[J]. Prog Energy Combust Sci, 2018, 67: 31-68.
[59]	Mathieu O, Petersen E L. Experimental and modeling study on the high-temperature oxidation of ammonia and related NO_x chemistry[J]. Combust Flame, 2015, 162(3): 554-570.
[60]	Hayakawa A, Goto T, Mimoto R, et al. Laminar burning velocity and Markstein length of ammonia/air premixed flames at various pressures[J]. Fuel, 2015, 159: 98-106.
[61]	SHU Bo, Vallabhuni S K, HE Xiaoyu, et al. A shock tube and modeling study on the autoignition properties of ammonia at intermediate temperatures[J]. Proc Combust Inst, 2019, 37(1): 205-211.
[62]	CHEN Jundie, JIANG Xue, QIN Xiaokang, et al. Effect of hydrogen blending on the high temperature auto-ignition of ammonia at elevated pressure[J]. Fuel, 2021, 287: 119563.
[63]	Pochet M, Dias V, Moreau B, et al. Experimental and numerical study, under LTC conditions, of ammonia ignition delay with and without hydrogen addition[J]. Proc Combust Inst, 2019, 37(1): 621-629.
[64]	HE Xiaoyu, Shu B, Nascimento D, et al. Auto-ignition kinetics of ammonia and ammonia/ hydrogen mixtures at intermediate temperatures and high pressures[J]. Combust Flame, 2019, 206: 189-200.
[65]	Dai Liming, Gersen S, Glarborg P, et al. Experimental and numerical analysis of the autoignition behavior of NH₃ and NH₃ / H₂ mixtures at high pressure[J]. Combust Flame, 2020, 215: 134-144.
[66]	LIAO Wanxiong, CHU Zhaohan, WANG Yiru, et al. An experimental and modeling study on auto-ignition of ammonia in an RCM with N₂O and H₂ addition[J]. Proc Combust Inst, 2023, 39(4): 4377-4385.
[67]	LIAO Wanxiong, WANG Yiru, CHU Zhaohan, et al. Chemical insights into the two-stage ignition behavior of NH₃ / H₂ mixtures in an RCM[J]. Combust Flame. 2023, 256: 112985.
[68]	Ichikawa A, Hayakawa A, Kitagawa Y, et al. Laminar burning velocity and Markstein length of ammonia/hydrogen/air premixed flames at elevated pressures[J]. Int'l J Hydro Energ, 2015, 40(30): 9570-9578.
[69]	HAN Xinlu, WANG Zhihua, Costa M, et al. Experimental and kinetic modeling study of laminar burning velocities of NH₃ / air, NH₃ / H₂ / air, NH₃ / CO/air and NH₃ / CH₄ / air premixed flames[J]. Combust Flame, 2019, 206: 214-226. doi: 10.1016/j.combustflame.2019.05.003
[70]	Lhuillier C, Brequigny P, Lamoureux N, et al. Experimental investigation on laminar burning velocities of ammonia / hydrogen / air mixtures at elevated temperatures[J]. Fuel, 2020, 263: 116653.
[71]	Shrestha K P, Lhuillier C, Barbosa A A, et al. An experimental and modeling study of ammonia with enriched oxygen content and ammonia / hydrogen laminar flame speed at elevated pressure and temperature[J]. Proc Combust Inst, 2021, 38(2): 2163-2174.
[72]	SONG Yu, Hashemi H, Christensen J M, et al. Ammonia oxidation at high pressure and intermediate temperat- ures[J]. Fuel, 2016, 181: 358-365.
[73]	Abián M, Benés M, Goñi A D, et al. Study of the oxidation of ammonia in a flow reactor: Experiments and kinetic modeling simulation[J]. Fuel, 2021, 300: 120979.
[74]	Stagni A, Arunthanayothin S, Dehue M, et al. Low- and intermediate-temperature ammonia / hydrogen oxidation in a flow reactor: Experiments and a wide-range kinetic modeling[J]. Chem Engi J, 2023, 471: 144577.
[75]	Sabia P, Manna M V, Cavaliere A, et al. Ammonia oxidation features in a jet stirred flow reactor: The role of NH₂ chemistry[J]. Fuel, 2020, 276: 118054.
[76]	ZHANG Xiaoyuan, Moosakutty S P, Rajan R P, et al. Combustion chemistry of ammonia / hydrogen mixtures: Jet-stirred reactor measurements and comprehensive kinetic modeling[J]. Combust Flame, 2021, 234: 111653.
[77]	TANG Ruoyue, XU Qiang, PAN Jiaying, et al. An experimental and modeling study of ammonia oxidation in a jet stirred reactor[J]. Combust Flame, 2022, 240: 112007.
[78]	Mercier A, Mounaïm-Rousselle C, Brequigny P, et al. Improvement of SI engine combustion with ammonia as fuel: Effect of ammonia dissociation prior to combus- tion[J]. Fuel Commun, 2022, 11: 100058.
[79]	Pyrc M, Gruca M, Tutak W and Jamrozik A. Assessment of the co-combustion process of ammonia with hydrogen in a research VCR piston engine[J]. Int'l J Hydro Energ, 2023, 48(7): 2821-2834
[80]	Westlye F R, Ivarsson A, Schramm J. Experimental investigation of nitrogen based emissions from an ammonia fueled SI-engine[J]. Fuel, 2013, 111: 239-247.
[81]	ZHOU Shangkun, CUI Baochong, YANG Wenjun, et al. An experimental and kinetic modeling study on NH₃ / air, NH₃ / H₂ / air, NH₃ / CO / air, and NH₃ / CH₄ / air premixed laminar flames at elevated temperature[J]. Combust Flame, 2023, 248: 112536.
[82]	ZHU Yuxiang, Curran H J, Girhe S, et al. The combustion chemistry of ammonia and ammonia / hydrogen mixtures: A comprehensive chemical kinetic modeling study[J]. Combust Flame, 2024, 260: 113239.
[83]	ZHANG Ridong, ZHANG Qihang, QI Yunliang, et al. A study on measuring ammonia-hydrogen IDTs and constructing an ammonia-hydrogen combustion mechanism at engine-relevant thermodynamic and fuel concentration conditions[J]. Int'l J Hydro Energ, 2024, 82: 786-800.
[84]	Lhuillier C, Brequigny P, Lamoureux N, et al. Experimental investigation on laminar burning velocities of ammonia/hydrogen/air mixtures at elevated temperatures[J]. Fuel, 2020, 263: 116653.
[85]	Otomo J, Koshi M, Mitsumori T, et al. Chemical kinetic modeling of ammonia oxidation with improved reaction mechanism for ammonia/air and ammonia/hydrogen/air combustion[J]. Int'l J Hydro Energ, 2018, 43(5): 3004-3014.
[86]	MEI Bowen, ZHANG Xiaoyuan, MA Siyuan, et al. Experimental and kinetic modeling investigation on the laminar flame propagation of ammonia under oxygen enrichment and elevated pressure conditions[J]. Combust Flame, 2019, 210: 236-246. doi: 10.1016/j.combustflame.2019.08.033
[87]	HAN Xinlu, WANG Zhihua, HE Yong, et al. Experimental and kinetic modeling study of laminar burning velocities of NH₃ / syngas / air premixed flames[J]. Combust Flame, 2020, 213: 1-13.
[88]	Glarborg P. The NH₃ / NO₂ / O₂ system: Constraining key steps in ammonia ignition and N₂O formation[J]. Combust Flame, 2023, 257: 112311.
[89]	Stagni A, Cavallotti C. H-abstractions by O₂, NO₂, NH₂, and HO₂ from H₂NO: Theoretical study and implications for ammonia low-temperature kinetics[J]. Proc Combust Inst, 2023, 39(1): 633-641.
[90]	WANG Qiao, WANG Huanhuan, CHEN Haodong, et al. New insights into the NH₃ / N₂O / Ar system: Key steps in N₂O evolution[C]// Proceed Combust Instit. 2024, 40(1-4): 105236.
[91]	Staszak M. Artificial intelligence in the modeling of chemical reactions kinetics[J]. Phy Sci Rev, 2023, 8(1): 51-72.
[92]	HAN Xu, JIA Ming, CHANG Yachao, et al. An improved approach towards more robust deep learning models for chemical kinetics[J]. Combust Flame, 2022, 238: 111934.
[93]	ZHENG Zhihao, LIN Xiaodong, YANG Ming, et al. Progress in the application of machine learning in combustion studies[J]. ES Energ Environ, 2020, 9(2): 1-14.
[94]	Ryu K, Zacharakis-Jutz G E, Kong S-C. Performance enhancement of ammonia-fueled engine by using dissociation catalyst for hydrogen generation[J]. Int'l J Hydro Energ, 2014, 39(5): 2390-2398.
[95]	Scharl V, Lackovic T, Sattelmayer T. Characterization of ammonia spray combustion and mixture formation under high-pressure, direct injection conditions[J]. Fuel, 2023, 333: 126454.
[96]	LIN Zhelong, LIU Shang, QI Yunliang, et al. Experimental study on the performance of a high compression ratio SI engine using alcohol/ammonia fuel[J]. Energy, 2024, 289: 129998.
[97]	LIU Shang, LIN Zhelong, QI Yunliang, et al. Combustion and emission characteristics of a spark ignition engine fueled with ammonia/gasoline and pure ammonia[J]. Appl Energy, 2024, 369: 123538.
[98]	Willmann M, Berger I, Bärow E. Woodward L’Orange’s new injector generation:An ideal platform for the combustion of E-fuels in large engines[A]// Liebl J (edit). Heavy-duty-, on- und off-highway-motor 2020. Wiesbaden: Springer Fachmedien Wiesbaden, 2021: 223-240.
[99]	CHENG Qiang, Ojanen K, Diao Y, et al. Dynamics of the ammonia spray using high-speed schlieren imaging[J]. SAE Int'l J Adv Curr Prac Mobil, 2022, 4(4): 1138-1153.
[100]	LI Shiyan, LI Tie, WANG Ning, et al. An investigation on near-field and far-field characteristics of superheated ammonia spray[J]. Fuel, 2022, 324: 124683.
[101]	FANG Yuwen, MA Xiao, ZHANG Yixiao, et al. Experimental investigation of high-pressure liquid ammonia injection under non-flash boiling and flash boiling conditions[J]. Energies, 2023, 16(6): 2843.
[102]	FANG Yuwen, ZHANG Kaiqi, MA Xiao, et al. Droplet measurement of high-pressure liquid ammonia injection using PDPA[R]. SAE Technical Paper, 2023-01-1637.
[103]	Payri R, García-Oliver J M, Bracho G, et al. Experimental characterization of direct injection liquid ammonia sprays under non-reacting diesel-like conditions[J]. Fuel, 2024, 362: 130851.
[104]	Bjørgen K O P, Emberson D R, Løvås T. Combustion of liquid ammonia and diesel in a compression ignition engine operated in high-pressure dual fuel mode[J]. Fuel, 2024, 360: 130269.
[105]	ZHOU Xinyi, LI Tie, WANG Ning, et al. Pilot diesel-ignited ammonia dual fuel low-speed marine engines: A comparative analysis of ammonia premixed and high-pressure spray combustion modes with CFD simulation[J]. Renew Sustain Energ Rev, 2023, 173: 113108.
[106]	LIU Long, WU Yue, WANG Yang, et al. Exploration of environmentally friendly marine power technology -ammonia/diesel stratified injection[J]. J Clean Product. 2022, 380: 135014.
[107]	LIN Zhelong, LIU Shang, SUN Qiyang, et al. Effect of injection and ignition strategy on an ammonia direct injection-Hydrogen jet ignition (ADI-HJI) engine[J]. Energy, 2024, 306: 132502.
[108]	LIU Long, WU Zan, TAN Fusheng, et al. CFD investigation the combustion characteristic of ammonia in low-speed marine engine under different combustion modes[J]. Fuel, 2023, 351: 128906.
[109]	Dober G, Hoffmann G, Doradoux L, et al. Direct injection systems for hydrogen engines[J]. MTZ Worldwide, 2021, 82(12): 60-65.
[110]	Schneider T. It is critical to find alternative low- or no-emission solutions[J]. MTZ Worldwide, 2023, 84(1): 24-27.
[111]	Beauregard G. Findings of hydrogen internal combustion engine durability[R]. Electric Trans Engineering Corporation, 2010.
[112]	LU Anhui, Nitz J-J, Comotti M, et al. Spatially and size selective synthesis of fe-based nanoparticles on ordered mesoporous supports as highly active and stable catalysts for ammonia decomposition[J]. J Am Chem Soc, 2010, 132(40): 14152-14162. doi: 10.1021/ja105308e pmid: 20849104
[113]	YIN Shuangfeng, ZHANG Qinhui, XU Boqing, et al. Investigation on the catalysis of CO_x-free hydrogen generation from ammonia[J]. J Catal, 2004, 224(2): 384-396.
[114]	YIN Shuangfeng, XU Boqing, ZHU Weixia, et al. Carbon nanotubes-supported Ru catalyst for the generation of CO_x-free hydrogen from ammonia[J]. Catal Today, 2004, 93: 27-38.
[115]	LIANG Changhai, LI Wenzhen, WEI Zhaobin, et al. Catalytic decomposition of ammonia over nitrided MoN_x / α-Al₂O₃ and NiMoNy / α-Al₂O₃ catalysts[J]. Ind Engi Chem Res, 2000, 39(10): 3694-3697.
[116]	Hacker V, Kordesch K. Ammonia crackers[M]// Vielstich W, Lamm A, Gasteiger H A, et al. Handbook of Fuel Cells (edit). Heoboken: John Wiley & Sons, Inc., 2010: 121-126.
[117]	Chiuta S, Everson R C, Neomagus H W J P, et al. Reactor technology options for distributed hydrogen generation via ammonia decomposition: A review[J]. Int'l J Hydro Energ, 2013, 38(35): 14968-14991.
[118]	Ezzat M F, Dincer I. Development and assessment of a new hybrid vehicle with ammonia and hydrogen[J]. Appl Energ, 2018, 219: 226-239.
[119]	Koike M, Suzuoki T, Takeuchi T, et al. Cold-start performance of an ammonia-fueled spark ignition engine with an on-board fuel reformer[J]. Int'l J Hydro Energ, 2021, 46(50): 25689-25698.
[120]	Goshome K, Yamada T, Miyaoka H, et al. High compressed hydrogen production via direct electrolysis of liquid ammonia[J]. Int'l J Hydro Energ, 2016, 41(33): 14529-14534.

时间	论文作者	点火模式	压缩比	掺氨率/ %	热效率/ %
2011	S.C.M?rch et al^[1]	SI	6.2~13.6	0~95	35.4(ITE)
2013	S.Frigo，et al^[2]	SI	10.7	0~95	26.0(BTE)
2015	M. Comotti，et al^[3]	SI	10.7	-	28.0(BTE)
2017	M. Pochet，et al^[4]	HCCI	16.0	0~70	-
2020	C. Lhuillier，et al^[5]	SI	10.5	46~100	39.0(ITE)
2020	M. Pochet，et al^[6]	HCCI	22.0	0~94	-
2021	C. Mouna?m-Rousselle，et al^[7]	SI	10.5	90~100	35.0(ITE)
2021	JI Changwei，et al^[8]	SI	9.5	0~3	34.2(ITE)
2022	GU Xin et al^[9]	SI	9.5	0~3	34.0(ITE)
2022	GU Xin，et al^[10]	SI	9.5	6.7~13.8	33.5(ITE)
2023	LIU Zongkuan，et al^[11]	JI	14.0	97.5	36.5(ITE)
2023	LIU Zongkuan，et al^[12]	JI	14.0	100	32.5(ITE)
2023	LIU Zongkuan，et al^[13]	JI	14.0	97.5	35.7(ITE)
2023	QI Yunliang，et al^[14]	JI	17.3	95	41.4(ITE)
2023	LIN Zhelong，et al^[15]	SI	15.5	48.8~67.2	44.3(ITE)
2024	WANG Zhi，et al^[16]	JI	17.3	95.6~97.9	42.5(ITE)

时间	论文作者	点火模式	压缩比	掺氨率/ %	热效率/ %
2011	S.C.M?rch et al^[1]	SI	6.2~13.6	0~95	35.4(ITE)
2013	S.Frigo，et al^[2]	SI	10.7	0~95	26.0(BTE)
2015	M. Comotti，et al^[3]	SI	10.7	-	28.0(BTE)
2017	M. Pochet，et al^[4]	HCCI	16.0	0~70	-
2020	C. Lhuillier，et al^[5]	SI	10.5	46~100	39.0(ITE)
2020	M. Pochet，et al^[6]	HCCI	22.0	0~94	-
2021	C. Mouna?m-Rousselle，et al^[7]	SI	10.5	90~100	35.0(ITE)
2021	JI Changwei，et al^[8]	SI	9.5	0~3	34.2(ITE)
2022	GU Xin et al^[9]	SI	9.5	0~3	34.0(ITE)
2022	GU Xin，et al^[10]	SI	9.5	6.7~13.8	33.5(ITE)
2023	LIU Zongkuan，et al^[11]	JI	14.0	97.5	36.5(ITE)
2023	LIU Zongkuan，et al^[12]	JI	14.0	100	32.5(ITE)
2023	LIU Zongkuan，et al^[13]	JI	14.0	97.5	35.7(ITE)
2023	QI Yunliang，et al^[14]	JI	17.3	95	41.4(ITE)
2023	LIN Zhelong，et al^[15]	SI	15.5	48.8~67.2	44.3(ITE)
2024	WANG Zhi，et al^[16]	JI	17.3	95.6~97.9	42.5(ITE)

No.	作者	年份	物种数/反应数	验证燃料	验证参数
1	P. Glarborg，et al^[58]	2018	151 / 1397	NH₃/ H₂/ C₁-C₂	-
2	J. Otomo，et al^[85]	2018	32 / 213	NH₃/ H₂	IDT / LFS
3	MEI Bowen，et al^[86]	2019	38 / 265	NH₃	LFS
5	HAN Xinlu，et al^[87]	2020	35 / 177	NH₃/ syngas	IDT/LFS
6	DAI Liming，et al^[65]	2020	151 / 1392	NH₃/ H₂	IDT
7	ZHANG Xiaoyuan，et al^[76]	2021	38 / 263	NH₃/ H₂	SMF
8	P. K. Shrestha，et al^[71]	2021	125 / 1 099	NH₃/ H₂/ DME	LFS
9	TANG Ruoyue，et al^[77]	2022	35 / 211	NH₃	SMF
10	LIAO Wanxiong，et al^[66]	2022	38 / 262	NH₃/ H₂	IDT/SMF
11	P. Glarborg^[88]	2022	41 / 270	NH₃	SMF
12	A. Stagni，et al^[89]	2023	31 / 205	NH₃	IDT / SMF
13	ZHOU Shangkun，et al^[81]	2023	169 / 1268	NH₃/ H₂/ CH₄/ CO	IDT / LFS / SMF
14	ZHU Yuxiang，et al^[82]	2024	43 / 312	NH₃/ H₂/ CH₄/ C₂H₆	IDT / LFS / SMF
15	ZHANG Ridong，et al^[83]	2024	31 / 214	NH₃/ H₂	IDT / LFS / SMF

No.	作者	年份	物种数/反应数	验证燃料	验证参数
1	P. Glarborg，et al^[58]	2018	151 / 1397	NH₃/ H₂/ C₁-C₂	-
2	J. Otomo，et al^[85]	2018	32 / 213	NH₃/ H₂	IDT / LFS
3	MEI Bowen，et al^[86]	2019	38 / 265	NH₃	LFS
5	HAN Xinlu，et al^[87]	2020	35 / 177	NH₃/ syngas	IDT/LFS
6	DAI Liming，et al^[65]	2020	151 / 1392	NH₃/ H₂	IDT
7	ZHANG Xiaoyuan，et al^[76]	2021	38 / 263	NH₃/ H₂	SMF
8	P. K. Shrestha，et al^[71]	2021	125 / 1 099	NH₃/ H₂/ DME	LFS
9	TANG Ruoyue，et al^[77]	2022	35 / 211	NH₃	SMF
10	LIAO Wanxiong，et al^[66]	2022	38 / 262	NH₃/ H₂	IDT/SMF
11	P. Glarborg^[88]	2022	41 / 270	NH₃	SMF
12	A. Stagni，et al^[89]	2023	31 / 205	NH₃	IDT / SMF
13	ZHOU Shangkun，et al^[81]	2023	169 / 1268	NH₃/ H₂/ CH₄/ CO	IDT / LFS / SMF
14	ZHU Yuxiang，et al^[82]	2024	43 / 312	NH₃/ H₂/ CH₄/ C₂H₆	IDT / LFS / SMF
15	ZHANG Ridong，et al^[83]	2024	31 / 214	NH₃/ H₂	IDT / LFS / SMF

氨氢融合零碳内燃机燃烧过程综述

Overview of the combustion of ammonia-hydrogen internal combustion engines

RichHTML

PDF

可视化

摘要/Abstract

引用本文

使用本文

图/表 27

参考文献 120

相关文章 0

编辑推荐

Metrics

本文评价

期刊信息

在线期刊

作者中心

审稿中心

联系我们
